DIP 50 Dry Ice Pelletizer

Code: IS-DIP-50

ICEsonic DIP 50 Dry Ice Pelletizer is capable of producing 50 kg/h of high density dry ice 24 hours a day, every day. The DIP 50 uses the latest technology to bring you high efficiency and high quality dry ice production. As standard it produces 3mm dry ice pellets and can be optioned to produce up to 16mm pellets. It is industry 4.0 ready and features an intuitive Siemens HMI for automated and manual operation and a variety of other features to make dry ice production as simple as possible. It can be optioned with an "ICEsonic CONNECT" module for remote monitoring and management.

Production Capacity 50 kg/h (110 lbs/h) with 3mm (1/8") pellets
Pellet Size Range 3.0-16mm (1/8-5/8")
Touch Screen Yes
Automation Ready Yes
Power Supply 400V 50Hz 3Ph + PE or 480V 60Hz 3Ph + PE
Max Power Consumption 2.5 kW
CO₂ Inlet Connection 1/2“ BSP female
CO₂ Source Storage tank, liquid phase, 1500 - 2200 Kpa (217 - 319 psi)
Connectivity and Remote Access Optional Ethernet, WiFi and 4G modules
Weight 280 kg (617 lbs)
Dimensions 700x1100x1000mm (28x43x39")
